CAT#:
86-1830
Eppendorf
Mastercycler® Nexus GX2e
Control Panel or Software Req., 1 Thermal Cycler/Unit
Product Overview
- Large block for large assays - small block for small assays
- Intuitive graphic programming
- Universal block for strips, 0.1 mL, 0.2 mL and 0.5 mL PCR tubes
- Small footprint
- With 8 coloumn gradient for PCR optimization
- E-mail notification
- flexlid concept allows use of all types of consumables with automatic height adjustment of the lid
Technical Specifications
| Unit Can Only Be Controlled1) | ■ |
| Thermoblock | Aluminum |
| Sample Capacity | 64/32 × 0.2 mL PCR tubes or up to 24/10 × 0.5 mL PCR tubes |
| Heating Technology | Peltier elements, Triple Circuit Technology |
| Temperature Control Mode | Fast, Standard, Safe |
| Temperature Control Range Of the Block | 4 – 99 °C |
| Intuitive Graphic Programming | – |
| Gradient Range | 1 – 12 °C |
| Gradient Temperature Control Range | 30 – 99 °C |
| Block Homogeneity 20 – 72 °C | ≤ ±0.3 °C |
| Control Accuracy | ±0.2 °C |
| E-mail Notification | ■ |
| Product Type | PCR |
| Flexlid® Concept | ■ |
| 2 Years Warranty | ■ |
| Universal Block For 0.2 Ml and 0.5 Ml Vessels | ■ |
| Gradient Block | Over 8 rows |
| Unit Can Control 2 Other Units In Network | – |
| USB Port | – |
| Block Homogeneity 90 °C | ≤ ±0.4 °C |
| Heating Rate | max. 3 °C/s2) |
| Cooling Rate | max. 2 °C/s2) |
| Lid Descent | flexlid® technology, with TSP |
| Lid Temperature Range | 37 – 110 °C |
| Interfaces | CAN_in/CAN_out, Ethernet |
| Power Supply | 100 – 110 V, 50 – 60 Hz |
| Max. Power Consumption | 700 W |
| Total Weight | 10.5 kg |
| Dimensions (W x D x H) | 25 × 41.2 × 33 cm / 9.8 × 16.2 × 13 in |
| Number Of Programs On Device | > 700 |
| Remote Device Monitoring and Notifications (visionize®) | VisioNize® box enabled |
Technical Documents
- 001 – Correct Temperature? – Yes!
- Master of Class
- Perfect Asymmetry
- Mastercycler® nexus, nexus X2(e), nexus flat/ eco/ flat eco/ gradient/ eco/ gradient eco/ flat/ X2 (e)/ GSX1 (e)/ GSX2(e)/ SX1(e)
- Mastercycler nexus
- Self-Test Dongle for Mastercycler pro and Mastercycler nexus
- 032 – Eppendorf Mastercycler: Meeting all your PCR needs with reliability and flexibility
- 243 – The Mastercycler nexus combines high energy efficiency with very low noise generation
- 244 – Excellent temperature homogeneity contributes to a high PCR performance of the Mastercycler nexus Keywords: block homogeneity
- 289 – Straightforward PCR optimization and highly flexible operation on the dual block thermocycler Mastercycler® nexus GX2
Detailed Description
The Mastercycler nexus X2 is Eppendorf's solution for busy PCR labs. Two totally independent protocols can be run on the two blocks. This allows two PCR users in the lab to start and end their PCR reactions whenever they want. One of the assays can have up to 64 samples. With less than 40 dB[a] noise emission, the nexus is whisper quiet but also very energy efficient.
The Mastercycler nexus X2 gives you the ability to run two totally independent protocols at the same time. Smaller assays fit nicely on the 32-well-block - larger assays can exceed 48 samples and run on the 64-well-block. The larger block is available with a gradient function. As every member of the Mastercycler nexus family, the Mastercycler nexus X2 can be combined with all other family members in a network of up to 3 units. In combination with Eppendorf’s PCR Tubes, PCR Strips or divisible plates, the Mastercycler nexus X2 will give you consistent and publishable results - every day!
The Mastercycler nexus X2 gives you the ability to run two totally independent protocols at the same time. Smaller assays fit nicely on the 32-well-block - larger assays can exceed 48 samples and run on the 64-well-block. The larger block is available with a gradient function. As every member of the Mastercycler nexus family, the Mastercycler nexus X2 can be combined with all other family members in a network of up to 3 units. In combination with Eppendorf’s PCR Tubes, PCR Strips or divisible plates, the Mastercycler nexus X2 will give you consistent and publishable results - every day!
